Burndy YAV8CL1BOX - Mechanical Lug Connector 600V
Burndy YAV8CL1BOX - Mechanical Lug Connector 600V

Burndy YAV8CL1BOX - Mechanical Lug Connector 600V

Burndy
Price
Save $-2.07
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
The Burndy YAV8CL1BOX is a mechanical lug connector designed for terminating and splicing aluminum or copper conductors in electrical power distribution systems. It is rated for a maximum voltage of 600V and accommodates a current range dependent on the conductor size, supporting wire sizes from #8 AWG to 350 kcmil. Constructed from high-strength aluminum alloy, this connector features a single-barrel, set-screw design for secure, reliable connections and weighs 0.46 lb. It complies with UL 486A-486B and CSA C22.2 No. 65 standards, ensuring safety and performance in industrial environments. Typical applications include panelboards, switchgear, and transformer connections in commercial and industrial settings.

Key Features & Specifications
  • Type: Mechanical lug connector, aluminum alloy, set-screw termination
  • Voltage Rating: 600V AC/DC
  • Current Rating: Dependent on conductor size (up to 350 kcmil)
  • Dimensions: Not specified
  • Standards: UL 486A-486B, CSA C22.2 No. 65
  • Applications: Panelboards, switchgear, transformer connections
  • Wire Size: #8 AWG to 350 kcmil
  • Metal Type: Aluminum
  • Connection: Single barrel, set-screw
  • Weight: 0.46 lb


Product Identification
  • UPC: 781810541203
  • GTIN: 00781810541203
