Eaton XTPRP16BC1 is an IEC motor control manual motor protector designed for thermal-magnetic protection of three-phase motors with adjustable overload settings. It is rated for 0.16 A with an adjustable thermal range of 0.1 to 0.16 A and a magnetic trip response of 2.2 A, operating at a short-circuit current rating of 50 kA at 600 V AC. The device features a compact 45 mm frame (Frame B) with a rotary manual disconnect, Class 10 trip characteristic, and screw terminals for DIN rail mounting, weighing 0.5 lb with dimensions of 2 in x 4 in x 4 in (Length/Depth x Height x Width). It is ATEX Compliant, CE, CSA, UL 508 Group Motor Type E Compliant, and UL Listed, meeting NEC 430 and CEC Rule 28-206 standards. This protector is suitable for group motor installations and Type E self-protected combination starters in industrial applications.

Key Features & Specifications
  • Type: Thermal-Magnetic Manual Motor Protector
  • Amperage Rating: 0.16 A
  • Adjustable Thermal Range: 0.1 - 0.16 A
  • Magnetic Trip Response: 2.2 A
  • Poles: 3-Phase
  • Frame Size: 45 mm (Frame B)
  • Trip Type: Class 10
  • Mounting: DIN Rail
  • Terminal Type: Screw
  • Short-Circuit Current Rating: 50 kA @ 600 V AC
  • Control Type: Rotary Manual Disconnect
  • Dimensions: 2 in x 4 in x 4 in (Length/Depth x Height x Width)
  • Weight: 0.5 lb
  • Certification: ATEX Compliant, CE, CSA, UL 508 Group Motor Type E Compliant, UL Listed
  • Country of Origin: Germany


Product Identification
  • UPC: 786685691084
  • GTIN: 04015082653309
