Eaton XJG94HDG - Disconnect Switch 600V 200A NEMA 4X
Eaton XJG94HDG - Disconnect Switch 600V 200A NEMA 4X

Eaton XJG94HDG - Disconnect Switch 600V 200A NEMA 4X

Eaton
Price
Save $98.59
/
Condition
  • Low stock - 3 items left
  • Backordered, shipping soon
Call for Price
Eaton XJG94HDG is a heavy-duty industrial disconnect switch designed for reliable circuit isolation and safety lockout/tagout applications. This robust switch is rated for 600V AC and 200A continuous current, featuring a compact NEMA 4X stainless steel enclosure for corrosion resistance in harsh environments. The unit weighs 24.2 lb and is constructed with a visible blade mechanism for positive confirmation of circuit status. It complies with UL 98 and CSA C22.2 standards for branch circuit disconnect switches, making it suitable for motor control centers, panelboards, and industrial machinery requiring a non-fusible disconnect.

Key Features & Specifications
  • Type: Heavy-duty non-fusible disconnect switch, visible blade, stainless steel enclosure
  • Voltage Rating: 600V AC
  • Current Rating: 200A
  • Dimensions: Compact NEMA 4X enclosure
  • Standards: UL 98, CSA C22.2
  • Applications: Industrial motor control, panelboard isolation, machinery disconnect
  • Switch Type: Non-fusible, visible blade
  • Configuration: 3-pole, 3-phase
  • Coil Voltage Maximum: Not applicable (manual operation)
  • Temp Rating: -20°C to 60°C
  • Shipping Dimensions: 12 x 10 x 8 inches (approx)
  • Phase: 3
  • Voltage: 600V AC
  • Amperage: 200A
  • AIC rating: 10kA at 600V AC
  • Connection: Line and load lugs
  • Poles: 3
  • Protection: Non-fusible, no overcurrent
  • Functions: Disconnect, lockout
  • Frame Size: 200A
  • Trip Type: Not applicable
  • Panel Type: NEMA 4X
  • Breaker Type: Not applicable
  • Control Voltage Minimum: Not applicable
  • Control Voltage Maximum: Not applicable
  • MCM Size: 250 MCM max
  • Metal Type: Stainless steel
  • Panel Style: Surface mount
  • Bus Type: Copper
  • Fuse Class: Not applicable
  • Insulation Temperature: 105°C
  • Inductance: Not specified
  • Impedance: Not specified
  • Barrels: Not applicable
  • Class Rating: Not applicable
  • Diameter: Not applicable
  • Velocity: Not applicable
  • Clip Center: Not applicable
  • Clas: Not applicable
  • Mounting: Surface
  • Hz: 50/60
  • Coil Material: Not applicable
  • Horse Power: 100 HP at 480V
  • Aux Contacts: 1 N.O. + 1 N.C.
  • CPT: Not included
  • Full Load Amps: 200A
  • Dist Voltage: 600V AC
  • Bucket Size: Not applicable
  • Bucket Style: Not applicable
  • Bucket Type: Not applicable
  • Full Load Amp Maximum: 200A
  • Full Load Amp Minimum: 0A
  • Enclosure: NEMA 4X stainless steel
  • Relay Style: Not applicable
  • Coil Voltage Minimum: Not applicable
  • Wire: Copper/Aluminum
  • Amperage Maximum: 200A
  • Amperage Minimum: 0A
  • Nema Rating: 4X
  • Switch Style: Heavy-duty
  • Wire Size: 14 AWG to 250 MCM
  • Certification: UL, CSA
  • Circuit Breaker Mounting Style: Not applicable
  • Terminal Connection: Box lugs
  • Frequency Rating: 50/60 Hz
  • Phase Connection: 3-phase
  • Standards: UL 98, CSA C22.2
  • Compatible Frames: Not applicable
  • Installation Type: Surface
  • Item QTY: 1
  • Nema Starter Size: Not applicable
  • Breaker Frame: Not applicable
  • Current Rating: 200A
  • Reverse Standoff Voltage: Not applicable
  • Watts: Not applicable
  • Peak Pulse Current: Not applicable
  • Breakdown Voltage (MIN VBR@IT ) (V): Not applicable
  • Breakdown Voltage (VBR@IT) (V): Not applicable
  • Polarity: Not applicable
  • Operating Temperature Maximum Celsius: 60°C
  • Max Clamp Voltage: Not applicable
  • On-State Current: Not applicable


Product Identification
  • UPC: 66227627157
  • GTIN: 00662276271579
