ITE VMS366B - Fusible Safety Switch 600A 600V (200kA AIC @480V)

ITE VMS366B is a panel-mounted fusible safety switch designed for high-current industrial power distribution systems. This 600V-rated switch features a 600A current capacity with a 200kA interrupting rating at 480V, housed in a rugged NEMA 1 enclosure measuring 19.685" x 20.866" x 13.78" (500 x 530 x 350 mm) and weighing 75 lb. Compliant with industrial safety standards, the three-phase Vacu-Break series switch accepts R, H, and K class fuses and integrates with FIP frames for heavy-duty motor control and main disconnect applications.

Key Features & Specifications

• Type: Fusible safety switch, panel mount, Vacu-Break design
• Voltage Rating: 600V AC
• Current Rating: 600A
• Dimensions: 19.685" x 20.866" x 13.78" (500 x 530 x 350 mm)
• Standards: NEMA 1 enclosure rating
• Applications: Industrial power distribution, motor control centers
• Switch Style: Fusible
• Configuration: Single
• Poles: 3
• Phase: 3
• AIC rating: 200kA@480V
• Fuse Class: R, H, K
• Compatible Frames: FIP
• Weight: 75 lb
• Country of Origin: United States

Product Identification

• UPC: 783643193451
• GTIN: 00783643193451
