ITE VMS365T - Fusible Safety Switch 400A (200kA@480V AIC, 3-Pole)

ITE VMS365T is a heavy-duty fusible safety switch designed for industrial power distribution systems requiring high interrupting capacity. This 600V-rated switch features a 400A current rating with a 200kA@480V AIC rating, housed in a NEMA 1 enclosure measuring 20.079" x 21.26" x 14.961" (509mm x 540mm x 380mm) and weighing 65 lb. The Vacu-Break series switch complies with UL standards and features Class R, H, and K fuse compatibility, three-pole single configuration, and FIP frame compatibility for three-phase applications.

Key Features & Specifications

• Type: VMS fusible safety switch with Vacu-Break technology
• Voltage Rating: 600V AC
• Current Rating: 400A
• Dimensions: 20.079" x 21.26" x 14.961" (509mm x 540mm x 380mm)
• Weight: 65 lb
• Standards: UL listed, NEMA 1 enclosure
• Applications: Industrial power distribution, motor control centers
• Switch Style: Fusible
• Configuration: Single
• Poles: 3
• AIC Rating: 200kA@480V
• Phase: 3
• Fuse Class: R, H, K
• Compatible Frames: FIP

Product Identification

• UPC: 783643193444
• GTIN: 00783643193444
