Boltswitch VL3611G4 - Fusible Disconnect Switch 2500A@240V (200kA AIC 3-Pole)

Boltswitch
Price
Save $-1,069.59
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Boltswitch VL3611G4 is a heavy-duty bolted pressure switch designed for high-current circuit protection in industrial power distribution systems. This fusible disconnect switch features a 240V AC voltage rating with a 2500A current capacity and 200kA interrupting rating at 240V, housed in a NEMA 1-rated enclosure for indoor use. The VL Series unit weighs 250 lb with a robust 3-pole single-configuration design using Class L fuses for reliable overcurrent protection. It complies with industry standards for bolted pressure switches in demanding environments. Typical applications include main service disconnects, motor control centers, and industrial power distribution panels requiring 3-phase circuit isolation.

Key Features & Specifications
  • Type: VL Series bolted pressure switch, fusible design with Class L fuse compatibility
  • Voltage Rating: 240V AC
  • Current Rating: 2500A
  • Configuration: Single
  • Poles: 3
  • AIC Rating: 200kA@240V
  • Phase: 3
  • NEMA Rating: 1 (indoor use)
  • Weight: 250 lb
  • Switch Style: Fusible disconnect
  • Standards: Industrial bolted pressure switch requirements
  • Applications: Power distribution, service entrances, MCCs
