Bussmann TRM1/4 - Midget Fuse 1A 250V (10kA Interrupting Rating)

Bussmann TRM1/4 is a low voltage fuse designed for providing reliable circuit protection in industrial applications. It features a 250V voltage rating and a 1A current rating for precise overcurrent protection. The fuse is constructed as a single-barrel midget class fuse with a compact 0.41-inch diameter and lightweight 0.01 lb design. It complies with industry standards and offers a 10kA interrupting rating at 250V for enhanced safety. Typical applications include protection of control circuits, instrumentation, and other sensitive electronic equipment where space constraints exist.

Key Features & Specifications

• Type: TRM Tri-Onic time-delay fuse, midget class
• Voltage Rating: 250V AC
• Current Rating: 1A
• Dimensions: 0.41" diameter
• Standards: Industry standard compliance
• Applications: Control circuits, instrumentation, sensitive electronics
• AIC rating: 10,000A @ 250V
• Class Rating: Midget
• Barrels: 1
• Weight: 0.01 lb

Product Identification

• UPC: 78200174103
• GTIN: 00782001741037
