Cutler Hammer TR1-4/10R - TR Fuse 1A 250V (RK5 Class, 200kA AIC)
Cutler Hammer TR1-4/10R - TR Fuse 1A 250V (RK5 Class, 200kA AIC)
Cutler Hammer TR1-4/10R - TR Fuse 1A 250V (RK5 Class, 200kA AIC)
Cutler Hammer TR1-4/10R - TR Fuse 1A 250V (RK5 Class, 200kA AIC)

Cutler Hammer TR1-4/10R - TR Fuse 1A 250V (RK5 Class, 200kA AIC)

Cutler Hammer
Price
Save $13.26
/
Title
  • Low stock - 7 items left
  • Backordered, shipping soon
Call for Price
The Cutler Hammer TR1-4/10R is a low-voltage current-limiting fuse from the Tri-Onic family, engineered to provide reliable overcurrent and short-circuit protection for electrical circuits. It features a 1A current rating and a 250V AC voltage rating, with a high 200kA interrupting capacity at its rated voltage to safely clear severe fault conditions. The fuse is constructed as a single-barrel unit with a 0.56-inch diameter and a Class RK5 rating, which offers a high degree of current limitation and time-delay characteristics. This component is designed for use in industrial control panels, motor branch circuits, and feeder circuits where robust circuit protection is required.

Key Features & Specifications
  • Type: Tri-Onic, TR, Low Voltage Current-Limiting Fuse, Time-Delay, Single Barrel
  • Voltage Rating: 250V AC
  • Current Rating: 1A
  • Dimensions: 0.56" Diameter
  • Standards: Class RK5
  • Applications: Industrial Control Panels, Motor Branch Circuits, Feeder Circuits
  • AIC rating: 200kA @ 250V AC
  • Weight: 5.19 lb
  • Barrels: 1
  • Family: Tri-Onic


Product Identification
  • UPC: 782001747619
  • GTIN: 00782001747619
