ABB S203-C50 - Molded Case 50A 480V 3-Pole
ABB S203-C50 - Molded Case 50A 480V 3-Pole

ABB S203-C50 - Molded Case 50A 480V 3-Pole

ABB
Price
Save $195.60
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
ABB S203-C50 is a 3-pole molded case circuit breaker from the S 200 Series, designed to provide overcurrent protection through thermal-magnetic tripping with long time and instantaneous trip functions. It is rated for 50A at 480V AC, with a 6kA interrupting capacity at 480V, and supports 3-phase operation via a feed-thru connection. The unit measures 69 mm in depth, 88 mm in height, and 52.5 mm in width, weighing 2.87 lb, and accepts wire sizes from AWG 18 to AWG 8 (or AWG 18 to AWG 4 depending on configuration). It is certified to EN, IEC, and UL standards, with an operating temperature range of -13°F to 158°F (-25°C to 70°C). This breaker is suited for industrial applications requiring reliable branch circuit protection in panelboards or distribution systems.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal Magnetic, 3-Pole
  • Voltage Rating: 480V AC
  • Current Rating: 50A
  • Dimensions: Depth / Length 69 mm x Height 88 mm x Width 52.5 mm
  • Standards: EN, IEC, UL
  • Applications: Industrial branch circuit protection
  • Switch Type: Circuit Breaker
  • Configuration: 3-Pole, 3-Phase
  • Coil Voltage Maximum: Not applicable
  • Temp Rating: -13–158 °F (-25–70 °C)
  • Shipping Dimensions: Not specified
  • Phase: 3
  • Voltage: 480V
  • Amperage: 50A
  • AIC rating: 6kA@480V
  • Connection: Feed-Thru
  • Poles: 3
  • Protection: Thermal Magnetic
  • Functions: Long Time and Instantaneous Trip
  • Frame Size: S 200 Series
  • Trip Type: Thermal Magnetic
  • Panel Type: Not specified
  • Breaker Type: Molded Case
  • Control Voltage Minimum: Not applicable
  • Control Voltage Maximum: Not applicable
  • MCM Size: Not applicable
  • Metal Type: Not specified
  • Panel Style: Not specified
  • Bus Type: Not specified
  • Fuse Class: Not applicable
  • Insulation Temperature: Not specified
  • Inductance: Not applicable
  • Impedance: Not applicable
  • Barrels: Not applicable
  • Class Rating: Not applicable
  • Diameter: Not applicable
  • Velocity: Not applicable
  • Clip Center: Not applicable
  • Clas: Not applicable
  • Mounting: Not specified
  • Hz: Not specified
  • Coil Material: Not applicable
  • Horse Power: Not specified
  • Aux Contacts: Not specified
  • CPT: Not specified
  • Full Load Amps: Not specified
  • Dist Voltage: Not specified
  • Bucket Size: Not applicable
  • Bucket Style: Not applicable
  • Bucket Type: Not applicable
  • Full Load Amp Maximum: Not specified
  • Full Load Amp Minimum: Not specified
  • Enclosure: Not specified
  • Relay Style: Not applicable
  • Coil Voltage Minimum: Not applicable
  • Wire: Not specified
  • Amperage Maximum: 50A
  • Amperage Minimum: Not specified
  • Nema Rating: Not specified
  • Switch Style: Not specified
  • Wire Size: AWG 18 to AWG 8, AWG 18 to AWG 4
  • Certification: EN, IEC, UL
  • Circuit Breaker Mounting Style: Not specified
  • Terminal Connection: Feed-Thru
  • Frequency Rating: Not specified
  • Phase Connection: 3-Phase
  • Standards: EN, IEC, UL
  • Compatible Frames: S 200 Series
  • Installation Type: Not specified
  • Item QTY: 1
  • Nema Starter Size: Not applicable
  • Breaker Frame: S 200 Series
  • Current Rating: 50A
  • Reverse Standoff Voltage: Not applicable
  • Watts: Not specified
  • Peak Pulse Current: Not applicable
  • Breakdown Voltage (MIN VBR@IT ) (V): Not applicable
  • Breakdown Voltage (VBR@IT) (V): Not applicable
  • Polarity: Not applicable
  • Operating Temperature Maximum Celsius: 70 °C
  • Max Clamp Voltage: Not applicable
  • On-State Current: Not applicable


Product Identification
  • UPC: 01677955106
  • GTIN: 04016779551069
