RFS15 Gould RFS Series Low Voltage Fuse 600V 15A Fuse - Essential Electric Supply
RFS15 Gould RFS Series Low Voltage Fuse 600V 15A Fuse - Essential Electric Supply

Cutler Hammer RFS15 - Class H Fuse 15A 600V (10kA AIC)

Cutler Hammer
Price
Save $-30.43
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Cutler Hammer RFS15 is a low-voltage, one-time fuse designed for overcurrent protection in industrial electrical systems. It provides a 15A current rating and 600V voltage rating for branch circuit and feeder protection, with an interrupting rating of 10kA at 600V AC. The fuse features a single-barrel, Class H construction with a 0.81-inch diameter and is built to meet industry standards for reliable performance in demanding environments. Typical applications include protecting motor circuits, transformers, and panelboards where high fault current interruption is required.

Key Features & Specifications
  • Type: Low Voltage, One-Time, Non-Time Delay, Class H Fuse
  • Voltage Rating: 600V AC
  • Current Rating: 15A
  • Dimensions: 0.81 in Diameter
  • Standards: Class H Rated
  • Applications: Motor Circuits, Transformers, Panelboards, Feeder Protection
  • AIC rating: 10kA @ 600V AC
  • Barrels: 1
  • Weight: 0.17 lb


Product Identification
  • UPC: 068938720797
  • GTIN: 00068938720797
