Bussmann RES-50 - Class H Renewable Fuse 50A (10kA@600V Interrupting Rating)

The Bussmann RES-50 is a Class H renewable fuse designed for overcurrent protection in industrial electrical systems. It features a 600V AC voltage rating and 50A current rating with an interrupting capacity of 10kA at 600V. The fuse construction includes a single-barrel REN-type renewable element within a compact form factor measuring 5.5 inches in height with a 1.06-inch diameter and weighing 1 lb. As part of Eaton's Super-Lag family, this fuse meets industry standards for time-delay protection characteristics. Typical applications include motor branch circuits, feeder circuits, and service entrance equipment where renewable fuse benefits are required.

Key Features & Specifications

• Type: Class H renewable fuse with time-delay characteristics
• Voltage Rating: 600V AC
• Current Rating: 50A
• Dimensions: 5.5" height × 0.78" width × 0.78" length
• Standards: Class H fuse standards
• Applications: Motor circuits, feeder protection, service entrance
• AIC rating: 10kA@600V
• Barrels: 1
• Diameter: 1.06 inches
• Class Rating: H
• Weight: 1 lb
• Family: Super-Lag

Product Identification

• UPC: 051712110501
• GTIN: 00051712110501
