Bussmann REN-5 - Class H Renewable Fuse 5A 250V (10kA Interrupting Rating)

Bussmann REN-5 is a Class H low-voltage fuse designed for circuit protection in industrial electrical systems, providing reliable overcurrent protection with a 5A current rating and 250V voltage rating. The fuse features a compact 2-inch length with a 0.56-inch diameter cylindrical body constructed for durable performance in demanding environments. It complies with industry standards for Class H fuses and carries a 10kA interrupting rating at 250V AC. Typical applications include motor branch circuits, feeder circuits, and general purpose electrical distribution systems where time-delay characteristics are required to handle temporary overload conditions.

Key Features & Specifications

• Type: Class H renewable cartridge fuse with time-delay characteristics
• Voltage Rating: 250V AC
• Current Rating: 5A
• Dimensions: 2" L × 0.56" W × 0.56" H (50.8mm × 14.2mm × 14.2mm)
• Standards: Class H fuse standards
• Applications: Motor branch circuits, feeder circuits, electrical distribution systems
• AIC rating: 10,000A @ 250V
• Barrels: 1
• Diameter: 0.56 inches (14.2mm)
• Class Rating: H
• Weight: 1 lb
• Family: Super-Lag

Product Identification

• UPC: 051712100052
• GTIN: 00051712100052
