Bussmann REN-35 - Class H Time-Delay Fuse 35A@250V (10kA AIC)

Bussmann REN-35 is a Class H low-voltage fuse designed for circuit protection in industrial applications, featuring a 35A current rating and 250V voltage rating. Its compact design measures 0.82" (20.8mm) in diameter and 2.98" (75.7mm) in length with a single-barrel construction, weighing 1 lb (0.45kg). Compliant with industry standards for Class H fuses, it offers 10kA interrupting capacity at 250V for reliable overcurrent protection. The Super-Lag series fuse is commonly used in motor circuits, transformers, and power distribution systems requiring time-delay characteristics.

Key Features & Specifications

• Type: REN series time-delay fuse with ceramic body
• Voltage Rating: 250V AC
• Current Rating: 35A
• Dimensions: 0.82" x 2.98" x 0.82" (20.8mm x 75.7mm x 20.8mm)
• Standards: Class H fuse compliance
• Applications: Motor circuits, transformers, power distribution
• AIC rating: 10kA@250V
• Diameter: 0.81" (20.6mm)
• Barrels: 1
• Weight: 1 lb (0.45kg)

Product Identification

• UPC: 051712100359
• GTIN: 00051712100359
