Bussmann REN-25 - Class H Time-Delay Fuse 25A 250V (10kA Interrupting Rating)

Bussmann REN-25 is a Class H Super-Lag time-delay fuse designed for industrial circuit protection applications requiring high interrupting capacity. This 25A rated fuse operates at 250V AC with an interrupting rating of 10kA, providing reliable overload and short-circuit protection. The compact single-barrel construction measures 2 inches in length with a 0.56-inch diameter, featuring robust construction suitable for demanding environments. Manufactured to meet industry standards for Class H fuses, this component is commonly deployed in motor branch circuits, transformer protection, and industrial control panels where time-delay characteristics prevent nuisance tripping during temporary overload conditions.

Key Features & Specifications

• Type: Class H time-delay fuse, single barrel construction
• Voltage Rating: 250V AC
• Current Rating: 25A
• Dimensions: 2" length × 0.56" height × 0.56" width
• Standards: Class H fuse compliance
• Applications: Motor circuits, transformer protection, industrial control panels
• AIC rating: 10,000A @ 250V
• Class Rating: H
• Barrels: 1
• Diameter: 0.56 inches
• Weight: 1 lb

Product Identification

• UPC: 051712100250
