Bussmann REN-15 - Class H Time-Delay Fuse 15A 250V (10kA AIC Rating)

Bussmann REN-15 is a Class H low-voltage fuse from the Super-Lag family designed for circuit protection in industrial applications. It features a 15A current rating and 250V voltage rating with an interrupting capacity of 10kA at 250V AC. The fuse measures 2 inches in length with a 0.56-inch diameter cylindrical body and weighs 1 lb, constructed as a single-barrel design for reliable performance. This Eaton-manufactured fuse meets industry standards for Class H fuses and is typically used in motor circuits, feeder circuits, and branch circuit protection where time-delay characteristics are required.

Key Features & Specifications

• Type: Class H time-delay fuse, single barrel construction
• Voltage Rating: 250V AC
• Current Rating: 15A
• Dimensions: 2" length × 0.56" diameter
• Weight: 1 lb
• Standards: Class H fuse standards
• Applications: Motor circuit protection, feeder circuits, branch circuits
• AIC rating: 10kA@250V
• Barrels: 1
• Class Rating: H
• Diameter: 0.56 inches
• Family: Super-Lag
• Country of Origin: Mexico

Product Identification

• UPC: 051712100151
• GTIN: 00051712100151
