Bussmann R601001CR - Class R Fuse 600V 100A (RK1, 5.19 lb)
Bussmann R601001CR - Class R Fuse 600V 100A (RK1, 5.19 lb)

Bussmann R601001CR - Class R Fuse 600V 100A (RK1, 5.19 lb)

Bussmann
Price
Save $-37.05
/
Condition
  • Low stock - 3 items left
  • Backordered, shipping soon
Call for Price
Bussmann R601001CR is a 600-volt, 100-amp Class R current-limiting fuse designed for branch circuit protection in industrial power distribution systems. It operates at a maximum voltage of 600VAC/300VDC with a 100-amp continuous current rating and a 200kA interrupting rating at 600VAC. The fuse features a ferrule-type construction with a 5.19 lb weight and a 2.75-inch diameter, 7.88-inch length, and 3.25-inch clip center. It complies with UL 248-9 and CSA C22.2 standards for Class RK1 fuses, ensuring reliable overcurrent protection. Typical applications include motor control centers, panelboards, and switchboards requiring high fault current interruption.

Key Features & Specifications
  • Type: Class R, current-limiting, ferrule fuse
  • Voltage Rating: 600VAC / 300VDC
  • Current Rating: 100A
  • Dimensions: 2.75 in diameter, 7.88 in length, 3.25 in clip center
  • Standards: UL 248-9, CSA C22.2
  • Applications: Branch circuit protection in industrial power distribution
  • Weight: 5.19 lb
  • Fuse Class: RK1
  • Interrupting Rating: 200kA at 600VAC
  • Mounting: Clip or bolted
  • Terminal Connection: Ferrule


Product Identification
  • UPC: Not provided
  • GTIN: Not provided
