Square D QOU2601021 - 60A 2-Pole Molded Case Breaker
Square D QOU2601021 - 60A 2-Pole Molded Case Breaker

Square D QOU2601021 - 60A 2-Pole Molded Case Breaker

Square D
Price
Save $80.30
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Square D QOU2601021 is a 2-pole molded case circuit breaker designed for overcurrent protection in residential and commercial power distribution systems. This thermal-magnetic breaker is rated for 60A at 120/240VAC with a 10kA interrupting capacity, providing both long-time and instantaneous trip functions. The unit features a bolt-on connection, accepts AWG 14 to AWG 2 aluminum or copper wire, and measures 4.05 inches in height by 2.25 inches in width by 2.95 inches in depth, weighing 1.06 lb. It is UL listed and IEC certified for single-phase applications, operating within a temperature range of -25 to 70°C. This breaker is suitable for use in load centers and panelboards requiring reliable thermal-magnetic protection.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker
  • Voltage Rating: 120/240V
  • Current Rating: 60A
  • Poles: 2
  • Connection: Bolt-On
  • Protection: Thermal Magnetic
  • Functions: Long Time and Instantaneous Trip
  • AIC Rating: 10kA@240V
  • Phase: 1
  • Wire Size: AWG 14...AWG 2 aluminium/copper
  • Dimensions: 4.05 in (102.87 mm) x 2.25 in (57.15 mm) x 2.95 in (74.93 mm) (Height x Width x Depth)
  • Weight: 1.06 lb
  • Temp Rating: -13–158 °F (-25–70 °C)
  • Certification: IEC, UL listed
  • Country of Origin: Mexico


Product Identification
  • UPC: 078590151850
  • GTIN: 00785901518501
