Square D QOU2301021 - Molded Case 30A 240V 2-Pole Breaker
Square D QOU2301021 - Molded Case 30A 240V 2-Pole Breaker

Square D QOU2301021 - Molded Case 30A 240V 2-Pole Breaker

Square D
Price
Save $80.30
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Square D QOU2301021 is a 2-pole molded case circuit breaker designed to provide overcurrent protection for electrical systems. This thermal magnetic breaker is rated for 30A at 240V with a 10kA interrupting capacity, and it utilizes a bolt-on connection for secure installation. The unit measures 4.05 inches in height, 2.25 inches in width, and 2.95 inches in depth, weighing 1.16 lb, and is constructed for single-phase applications. It is certified to IEC, UL, and CSA standards, ensuring compliance with industry safety requirements. This breaker is suitable for industrial applications where reliable long-time and instantaneous trip functions are needed, and it accepts wire sizes from AWG 14 to AWG 2 aluminum or copper.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker with thermal magnetic protection
  • Voltage Rating: 240V
  • Current Rating: 30A
  • Dimensions: 4.05 in (102.87 mm) x 2.25 in (57.15 mm) x 2.95 in (74.93 mm) (Height x Width x Depth)
  • Standards: IEC - UL listed - CSA
  • Applications: Industrial overcurrent protection
  • Poles: 2
  • Connection: Bolt-On
  • Protection: Thermal Magnetic
  • Functions: LI - Long-Time and Instantaneous Trip
  • Wire Size: AWG 14...AWG 2 aluminium/copper
  • AIC rating: 10kA@240V
  • Phase: 1
  • Temp Rating: -13–158 °F (-25–70 °C)
  • Country of Origin: Mexico
  • Weight: 1.16 lb


Product Identification
  • UPC: 785901517948
  • GTIN: 00785901517948
