Square D QOB2201201 - 20A 2-Pole Bolt-On Breaker
Square D QOB2201201 - 20A 2-Pole Bolt-On Breaker

Square D QOB2201201 - 20A 2-Pole Bolt-On Breaker

Square D
Price
Save $-124.38
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Square D QOB2201201 is a 2-pole, 20A bolt-on molded case circuit breaker from the QOB family, designed to provide thermal-magnetic overcurrent protection for branch circuits. It operates at 120/240VAC with a 10kA interrupting capacity at 120V, utilizing long-time and instantaneous trip functions to safeguard against overloads and short circuits. The breaker measures 3.0 in x 2.2 in x 2.9 in (76 mm x 57 mm x 74 mm), weighs 0.93 lb, and features pressure plate terminals accepting AWG 14 to AWG 8 copper or aluminum wire. It is UL Listed and CSA certified, with a temperature rating of -13°F to 158°F (-25°C to 70°C), making it suitable for single-phase industrial applications requiring reliable branch circuit protection.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, QOB Series, Bolt-On Mounting
  • Voltage Rating: 120/240VAC
  • Current Rating: 20A
  • Dimensions: 3.0 in (76 mm) x 2.2 in (57 mm) x 2.9 in (74 mm) (Height x Width x Depth)
  • Standards: UL Listed, CSA Certified
  • Applications: Branch circuit protection in industrial and commercial panels
  • Poles: 2
  • Phase: 1
  • AIC rating: 10kA@120V
  • Connection: Bolt-On
  • Protection: Thermal Magnetic
  • Functions: Long-Time and Instantaneous Trip
  • Wire Size: AWG 14 to AWG 8, Copper/Aluminum
  • Terminal Connection: Pressure Plate
  • Temp Rating: -13°F to 158°F (-25°C to 70°C)
  • Weight: 0.93 lb
  • Country of Origin: Mexico


Product Identification
  • UPC: 3606486144640
