Square D QOB115VH1021 - 15A 1-Pole Miniature Breaker (120/240VAC)
Square D QOB115VH1021 - 15A 1-Pole Miniature Breaker (120/240VAC)

Square D QOB115VH1021 - 15A 1-Pole Miniature Breaker (120/240VAC)

Square D
Price
Save $47.24
/
Condition
  • Low stock - 1 item left
  • Backordered, shipping soon
Call for Price
Square D QOB115VH1021 is a 1-pole, 15A miniature molded case circuit breaker from the QOB Series, designed for thermal-magnetic overcurrent protection in commercial and industrial power distribution systems. It operates at a voltage rating of 120/240VAC with a high interrupting capacity of 22kA at 120V, providing robust short-circuit and overload protection via its LI (Long-Time and Instantaneous) trip functions. The unit features a compact bolt-on mounting configuration with dimensions of 3.0 in (76 mm) x 1.5 in (38 mm) x 2.9 in (74 mm) and a weight of 0.67 lb, incorporating a pressure plate terminal connection for secure wiring. It is UL Listed and CSA certified, ensuring compliance with North American safety and performance standards. This breaker is typically applied in panelboards and load centers for commercial buildings, industrial facilities, and other environments requiring reliable branch circuit protection.

Key Features & Specifications
  • Type: QOB
  • Current Rating: 15A
  • Voltage Rating: 120/240VAC
  • Poles: 1
  • Protection: Thermal Magnetic
  • Functions: LI - Long-Time and Instantaneous
  • AIC Rating: 22kA@120V
  • Connection: Bolt-On
  • Terminal Connection: Pressure Plate
  • Phase: 1
  • Dimensions: 3.0 in (76 mm) x 1.5 in (38 mm) x 2.9 in (74 mm) (Height x Width x Depth)
  • Weight: 0.67 lb
  • Standards: CSA, UL Listed
  • Certification: UL Listed
  • Country of Origin: Mexico


Product Identification
  • UPC: 785901495550
  • GTIN: 00785901000000
