Square D QO2801021 - Molded Case 80A 2-Pole Breaker
Square D QO2801021 - Molded Case 80A 2-Pole Breaker

Square D QO2801021 - Molded Case 80A 2-Pole Breaker

Square D
Price
Save $-168.86
/
Condition
  • Low stock - 1 item left
  • Backordered, shipping soon
Call for Price
The Square D QO2801021 is a 2-pole molded case circuit breaker designed for overcurrent protection in residential and commercial power distribution systems. It is rated for 80A at 240V AC, providing a 10kA interrupting capacity at 240V, and features a thermal-magnetic trip mechanism with LI (Long-Time and Instantaneous) protection functions. This plug-in breaker measures 3.5 in (89 mm) x 2.2 in (57 mm) x 2.9 in (74 mm) and weighs 1 lb, accepting copper or aluminum wire from AWG 4 to AWG 2/0. It is UL Listed and operates within a temperature range of -13 to 158 °F (-25 to 70 °C), making it suitable for single-phase applications in QO load centers and panelboards.

Key Features & Specifications
  • Type: QO Molded Case Circuit Breaker, Thermal Magnetic
  • Voltage Rating: 240V AC
  • Current Rating: 80A
  • Dimensions: 3.5 in (89 mm) x 2.2 in (57 mm) x 2.9 in (74 mm) (Height x Width x Depth)
  • Standards: UL Listed
  • Applications: Overcurrent protection for branch circuits in residential and commercial panels
  • Switch Type: Toggle
  • Configuration: 2-Pole
  • Temp Rating: -13 to 158 °F (-25 to 70 °C)
  • Phase: 1
  • Voltage: 240V
  • Amperage: 80A
  • AIC rating: 10kA@240V
  • Connection: Plug-In
  • Poles: 2
  • Protection: Thermal Magnetic
  • Functions: LI - Long-Time and Instantaneous Trip
  • Frame Size: QO
  • Trip Type: Thermal Magnetic
  • Panel Type: QO Load Centers
  • Breaker Type: Molded Case
  • Wire Size: AWG 4 to AWG 2/0, Copper or Aluminum
  • Certification: UL Listed
  • Circuit Breaker Mounting Style: Plug-In
  • Terminal Connection: Lug
  • Frequency Rating: 60 Hz
  • Phase Connection: Single Phase
  • Standards: UL 489
  • Installation Type: Plug-In
  • Item QTY: 1
  • Breaker Frame: QO
  • Current Rating: 80A
  • Operating Temperature Maximum Celsius: 70 °C
  • Manufacturer: Schneider Electric
  • Family: QO Series
  • Country of Origin: Mexico
  • Weight: 1 lb


Product Identification
  • UPC: 785901030546
  • GTIN: 00785901030546
