Schneider Electric QO230EPD2100 - 30A 2-Pole Molded Case Breaker
Schneider Electric QO230EPD2100 - 30A 2-Pole Molded Case Breaker

Schneider Electric QO230EPD2100 - 30A 2-Pole Molded Case Breaker

Square D
Price
Save $245.14
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Schneider Electric QO230EPD2100 Circuit Breaker is a 2-pole, 30A molded case circuit breaker from the QO Series, designed for thermal-magnetic overcurrent protection in residential and commercial load centers. It operates at 240V AC with a 10kA interrupting capacity and provides long-time and instantaneous trip functions for reliable fault clearing. The unit measures 4.1 in (105 mm) x 2.2 in (57 mm) x 2.9 in (74 mm) and weighs 1.13 lb, featuring a plug-in connection for easy installation. It is UL listed and CSA certified, compliant with industry standards for single-phase applications. This breaker is suitable for protecting branch circuits in QO panelboards, with a temperature rating of -13°F to 158°F (-25°C to 70°C) and accepts copper or aluminum wire from AWG 14 to AWG 8.

Key Features & Specifications
  • Type: QO Molded Case Circuit Breaker, Thermal-Magnetic
  • Voltage Rating: 240V AC
  • Current Rating: 30A
  • Dimensions: 4.1 in (105 mm) x 2.2 in (57 mm) x 2.9 in (74 mm) (Height x Width x Depth)
  • Standards: UL, CSA
  • Applications: Residential and commercial load centers, branch circuit protection
  • Switch Type: Toggle
  • Configuration: 2-Pole
  • Coil Voltage Maximum: N/A
  • Temp Rating: -13°F to 158°F (-25°C to 70°C)
  • Shipping Dimensions: N/A
  • Phase: 1
  • Voltage: 240V
  • Amperage: 30A
  • AIC rating: 10kA@240V
  • Connection: Plug-In
  • Poles: 2
  • Protection: Thermal Magnetic
  • Functions: Long Time and Instantaneous Trip
  • Frame Size: QO
  • Trip Type: Thermal-Magnetic
  • Panel Type: QO Load Center
  • Breaker Type: Molded Case
  • Control Voltage Minimum: N/A
  • Control Voltage Maximum: N/A
  • MCM Size: N/A
  • Metal Type: N/A
  • Panel Style: N/A
  • Bus Type: N/A
  • Fuse Class: N/A
  • Insulation Temperature: N/A
  • Inductance: N/A
  • Impedance: N/A
  • Barrels: N/A
  • Class Rating: N/A
  • Diameter: N/A
  • Velocity: N/A
  • Clip Center: N/A
  • Clas: N/A
  • Mounting: Plug-In
  • Hz: 60 Hz
  • Coil Material: N/A
  • Horse Power: N/A
  • Aux Contacts: N/A
  • CPT: N/A
  • Full Load Amps: N/A
  • Dist Voltage: N/A
  • Bucket Size: N/A
  • Bucket Style: N/A
  • Bucket Type: N/A
  • Full Load Amp Maximum: N/A
  • Full Load Amp Minimum: N/A
  • Enclosure: N/A
  • Relay Style: N/A
  • Coil Voltage Minimum: N/A
  • Wire: Copper/Aluminum
  • Amperage Maximum: 30A
  • Amperage Minimum: N/A
  • Nema Rating: N/A
  • Switch Style: Toggle
  • Wire Size: AWG 14 to AWG 8, AWG 12 to AWG 8
  • Certification: UL, CSA
  • Circuit Breaker Mounting Style: Plug-In
  • Terminal Connection: Plug-In
  • Frequency Rating: 60 Hz
  • Phase Connection: 1-Phase
  • Standards: UL 489, CSA C22.2 No. 5
  • Compatible Frames: QO
  • Installation Type: Plug-In
  • Item QTY: 1
  • Nema Starter Size: N/A
  • Breaker Frame: QO
  • Current Rating: 30A
  • Reverse Standoff Voltage: N/A
  • Watts: N/A
  • Peak Pulse Current: N/A
  • Breakdown Voltage (MIN VBR@IT ) (V): N/A
  • Breakdown Voltage (VBR@IT) (V): N/A
  • Polarity: N/A
  • Operating Temperature Maximum Celsius: 70°C
  • Max Clamp Voltage: N/A
  • On-State Current: N/A


Product Identification
  • UPC: 785901891234
  • GTIN: 00785901891234
