Square D QO115VHDF - Circuit Breaker 15A 120V (Thermal Magnetic)
Square D QO115VHDF - Circuit Breaker 15A 120V (Thermal Magnetic)

Square D QO115VHDF - Circuit Breaker 15A 120V (Thermal Magnetic)

Square D
Price
Save $442.29
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
The Square D QO115VHDF is a single-pole molded case circuit breaker from the QO Series, designed for overcurrent protection in residential and commercial load centers. It is rated for 120V AC with a 15A current capacity and a 22kA interrupting rating at 120V, utilizing a thermal-magnetic trip mechanism for long-time and instantaneous protection. This plug-in breaker measures 4.8 in (121 mm) x 0.7 in (19 mm) x 2.9 in (74 mm) and weighs 0.25 lb, accepting AWG 14 to AWG 8 copper or aluminum wire. It is UL-listed and CSA-certified, operating within a temperature range of -13°F to 158°F (-25°C to 70°C), and is manufactured in Mexico by Schneider Electric. Typical applications include branch circuit protection in QO load centers and panelboards for lighting, appliance, and general-purpose circuits.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal Magnetic
  • Voltage Rating: 120V AC
  • Current Rating: 15A
  • Dimensions: 4.8 in (121 mm) x 0.7 in (19 mm) x 2.9 in (74 mm) (H x W x D)
  • Standards: UL, CSA
  • Applications: Residential and commercial load centers, branch circuit protection
  • Switch Type: Toggle
  • Configuration: Single Pole
  • Temp Rating: -13°F to 158°F (-25°C to 70°C)
  • Shipping Dimensions: 4.8 in x 0.7 in x 2.9 in
  • Phase: 1
  • Amperage: 15A
  • AIC rating: 22kA@120V
  • Connection: Plug-In
  • Poles: 1
  • Protection: Thermal Magnetic
  • Functions: Long Time and Instantaneous Trip
  • Frame Size: QO
  • Trip Type: Thermal Magnetic
  • Panel Type: QO Load Centers
  • Breaker Type: QO
  • Wire Size: AWG 14 to AWG 8, Copper/Aluminum
  • Metal Type: Copper/Aluminum compatible
  • Panel Style: QO
  • Bus Type: Plug-On
  • Mounting: Plug-In
  • Hz: 60 Hz
  • Horse Power: Not applicable
  • Enclosure: Open (for panel mounting)
  • Circuit Breaker Mounting Style: Plug-In
  • Terminal Connection: Lug
  • Frequency Rating: 60 Hz
  • Phase Connection: Single Phase
  • Standards: UL 489, CSA C22.2 No. 5
  • Installation Type: Panel Mount
  • Item QTY: 1
  • Breaker Frame: QO
  • Current Rating: 15A
  • Polarity: Single Pole
  • Operating Temperature Maximum Celsius: 70°C


Product Identification
  • UPC: 785901100072
