Square D QJA222001 - Molded Case 200A 240V Breaker
Square D QJA222001 - Molded Case 200A 240V Breaker

Square D QJA222001 - Molded Case 200A 240V Breaker

Square D
Price
Save $1,203.47
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
The Square D QJA222001 is a 2-pole molded case circuit breaker from the I-Line family, designed to provide thermal-magnetic protection for electrical systems. It is rated for 240V AC, 200A, with a 100kA interrupting capacity at 240V, and features long-time and instantaneous trip functions for overcurrent protection. This unit measures 6.47 inches in height, 3 inches in width, and 3.93 inches in depth, weighing 4.729 lb, and utilizes an I-Line style plug-in connection for panel mounting. It complies with UL, CSA, NEMA, and NOM-003-SCFI-2000 standards, certified for single-phase applications in an operating temperature range of -25 to 70 °C. Typical industrial applications include distribution panels and switchboards requiring high-fault current protection in commercial and light industrial environments.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal Magnetic
  • Voltage Rating: 240V AC
  • Current Rating: 200A
  • Poles: 2
  • AIC Rating: 100kA@240V
  • Phase: 1
  • Connection: I-Line Style Plug-In
  • Functions: Long Time and Instantaneous Trip
  • Dimensions: 6.47 in (164.34 mm) x 3 in (76.2 mm) x 3.93 in (99.82 mm) (Height x Width x Depth)
  • Weight: 4.729 lb
  • Temp Rating: -13–158 °F (-25–70 °C)
  • Standards: UL, CSA, NEMA, NOM-003-SCFI-2000
  • Certification: UL, CSA, NOM
  • Family: I-Line
  • Country of Origin: Mexico


Product Identification
  • UPC: 785901484325
  • GTIN: 00785901484325
