The Square D QGA220702 is a 70A, 2-pole molded case circuit breaker from the I-Line family, designed for thermal-magnetic protection in industrial power distribution systems. It operates at 240V with a 65kA interrupting capacity and supports wire sizes from AWG 4 to 300 kcmil for both aluminum and copper conductors. This unit features LI (Long-Time and Instantaneous) trip functions, measures 6.47 in x 3 in x 3.93 in (164.34 mm x 76.2 mm x 99.82 mm), weighs 4.729 lb, and uses an I-Line style plug-in connection. It complies with UL, CSA, NEMA, and NOM-003-SCFI-2000 standards, making it suitable for single-phase applications in switchboards, panelboards, and motor control centers.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal Magnetic, I-Line Plug-In
  • Voltage Rating: 240V
  • Current Rating: 70A
  • Dimensions: 6.47 in (164.34 mm) x 3 in (76.2 mm) x 3.93 in (99.82 mm) (Height x Width x Depth)
  • Standards: UL, CSA, NEMA, NOM-003-SCFI-2000
  • Applications: Industrial power distribution, switchboards, panelboards, motor control centers
  • Poles: 2
  • Connection: I-Line Style Plug-In
  • Protection: Thermal Magnetic
  • Functions: LI - Long-Time and Instantaneous
  • AIC rating: 65kA@240V
  • Phase: 1
  • Wire Size: AWG 4...300 kcmil aluminium/copper
  • Certification: UL, CSA, NOM
  • Weight: 4.729 lb
  • Manufacturer: Schneider Electric
  • Family: I-Line
  • Country of Origin: Mexico


Product Identification
  • UPC: 785901442424
