Siemens Q2100P - Molded Case 2-Pole 100A 120/240VAC 10kAIC
Siemens Q2100P - Molded Case 2-Pole 100A 120/240VAC 10kAIC

Siemens Q2100P - Molded Case 2-Pole 100A 120/240VAC 10kAIC

Siemens
Price
Save $-120.27
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Siemens Q2100P Circuit Breaker - Molded Case 2-Pole 100A 120/240VAC 10kAIC The Siemens Q2100P is a 2-pole molded case circuit breaker designed for overload and short-circuit protection in residential and light commercial load centers. It is rated for 100 amps at 120/240 volts AC with a 10,000 AIC interrupting capacity, ensuring reliable fault interruption. This compact breaker features a 1-inch per pole construction with a thermal-magnetic trip mechanism and weighs 1 lb. It is UL listed and meets CSA standards for safe installation in Siemens and compatible panelboards. Typical applications include main or branch circuit protection in lighting, appliance, and distribution panels.

Key Features & Specifications
  • Type: Molded Case, Thermal-Magnetic
  • Voltage Rating: 120/240 VAC
  • Current Rating: 100 A
  • Dimensions: 1-inch per pole width
  • Standards: UL Listed, CSA Certified
  • Applications: Residential and light commercial load centers, main or branch circuit protection
  • Switch Type: Toggle
  • Configuration: 2-Pole
  • Coil Voltage Maximum: N/A
  • Temp Rating: 40°C ambient
  • Shipping Dimensions: 3.5 x 2.5 x 1.5 in
  • Phase: 1-Phase
  • Voltage: 120/240 VAC
  • Amperage: 100 A
  • AIC rating: 10 kAIC @ 240 VAC
  • Connection: Line and Load Lug
  • Poles: 2
  • Protection: Overload and Short-Circuit
  • Functions: On/Off Switching, Trip Indication
  • Frame Size: QP
  • Trip Type: Thermal-Magnetic
  • Panel Type: Load Center
  • Breaker Type: Molded Case
  • Control Voltage Minimum: N/A
  • Control Voltage Maximum: N/A
  • MCM Size: 14 AWG - 2 AWG
  • Metal Type: Copper/Aluminum
  • Panel Style: Plug-On
  • Bus Type: Tin-Plated
  • Fuse Class: N/A
  • Insulation Temperature: 75°C
  • Inductance: N/A
  • Impedance: N/A
  • Barrels: N/A
  • Class Rating: N/A
  • Diameter: N/A
  • Velocity: N/A
  • Clip Center: 1.0 in
  • Clas: N/A
  • Mounting: Plug-On
  • Hz: 60 Hz
  • Coil Material: N/A
  • Horse Power: 3 HP @ 240 VAC
  • Aux Contacts: No
  • CPT: No
  • Full Load Amps: 100 A
  • Dist Voltage: N/A
  • Bucket Size: N/A
  • Bucket Style: N/A
  • Bucket Type: N/A
  • Full Load Amp Maximum: 100 A
  • Full Load Amp Minimum: 0 A
  • Enclosure: N/A
  • Relay Style: N/A
  • Coil Voltage Minimum: N/A
  • Wire: Copper/Aluminum
  • Amperage Maximum: 100 A
  • Amperage Minimum: 0 A
  • Nema Rating: N/A
  • Switch Style: Toggle
  • Wire Size: 14 AWG - 2 AWG
  • Certification: UL, CSA
  • Circuit Breaker Mounting Style: Plug-On
  • Terminal Connection: Lug
  • Frequency Rating: 60 Hz
  • Phase Connection: Single Phase
  • Standards: UL 489, CSA C22.2
  • Compatible Frames: Siemens QP, EQ, PL
  • Installation Type: Plug-On
  • Item QTY: 1
  • Nema Starter Size: N/A
  • Breaker Frame: QP
  • Current Rating: 100 A
  • Reverse Standoff Voltage: N/A
  • Watts: N/A
  • Peak Pulse Current: N/A
  • Breakdown Voltage (MIN VBR@IT ) (V): N/A
  • Breakdown Voltage (VBR@IT) (V): N/A
  • Polarity: N/A
  • Operating Temperature Maximum Celsius: 40°C
  • Max Clamp Voltage: N/A
  • On-State Current: N/A


Product Identification
  • UPC: 783643148680
  • GTIN: 00783643148680
