Square D PLA34060U31A - Molded Case Circuit Breaker 600A 480V
Square D PLA34060U31A - Molded Case Circuit Breaker 600A 480V

Square D PLA34060U31A - Molded Case Circuit Breaker 600A 480V

Square D
Price
Save $-19,261
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Square D PLA34060U31A is a 600A molded case circuit breaker designed to provide solid-state long-time and instantaneous (LI) protection for electrical systems. It operates at 480V with a 100kA interrupting capacity at that voltage, supporting 3-phase, 3-pole configurations. The unit features an I-Line style plug-in connection, accommodates wire sizes from 3 x AWG 3/0 to 500 kcmil aluminum or copper, and measures 12.86 in x 8.27 in x 8.05 in (H x W x D) with a weight of 32 lb. It complies with UL, CSA, NEMA, NOM-003-SCFI-2000, and IEC 60947-2 standards, operating within a temperature range of 28-158 °F (-2-70 °C). This breaker is suited for industrial applications requiring reliable overcurrent protection in distribution panels.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Solid State Trip
  • Voltage Rating: 480V
  • Current Rating: 600A
  • Dimensions: 12.86 in (326.64 mm) x 8.27 in (210.06 mm) x 8.05 in (204.47 mm) (Height x Width x Depth)
  • Weight: 32 lb
  • Poles: 3
  • Phase: 3
  • Connection: I-Line Style Plug-In
  • Protection: LI - Long-Time and Instantaneous
  • Wire Size: 3 x AWG 3/0...500 kcmil aluminium/copper
  • AIC Rating: 100kA@480V
  • Temp Rating: 28-158 °F (-2-70 °C)
  • Standards: UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
  • Certification: UL, CSA, NOM
  • Functions: LI - Long-Time and Instantaneous
  • Breaker Type: Molded Case
  • Installation Type: Plug-In
  • Circuit Breaker Mounting Style: I-Line
  • Terminal Connection: I-Line Style Plug-In
  • Frequency Rating: 50/60 Hz
  • Phase Connection: 3-Phase
  • Compatible Frames: I-Line
  • Item QTY: 1
  • Breaker Frame: PLA
  • Current Rating: 600A
  • Operating Temperature Maximum Celsius: 70 °C
  • Operating Temperature Minimum Celsius: -2 °C
  • Enclosure: Open
  • Switch Type: Circuit Breaker
  • Configuration: 3-Pole
  • Coil Voltage Maximum: Not applicable (Solid State)
  • Coil Voltage Minimum: Not applicable (Solid State)
  • Control Voltage Minimum: Not applicable (Solid State)
  • Control Voltage Maximum: Not applicable (Solid State)
  • MCM Size: 500 kcmil maximum
  • Metal Type: Copper/Aluminum
  • Panel Type: I-Line
  • Panel Style: I-Line
  • Bus Type: I-Line
  • Fuse Class: Not applicable (Circuit Breaker)
  • Insulation Temperature: 75 °C
  • Inductance: Not specified
  • Impedance: Not specified
  • Barrels: Not applicable
  • Class Rating: Not applicable
  • Diameter: Not applicable
  • Velocity: Not applicable
  • Clip Center: Not applicable
  • Clas: Not applicable
  • Mounting: Plug-In
  • Hz: 50/60 Hz
  • Coil Material: Not applicable (Solid State)
  • Horse Power: Not specified
  • Aux Contacts: Not specified
  • CPT: Not specified
  • Full Load Amps: 600A
  • Dist Voltage: 480V
  • Bucket Size: Not applicable
  • Bucket Style: Not applicable
  • Bucket Type: Not applicable
  • Full Load Amp Maximum: 600A
  • Full Load Amp Minimum: Not applicable
  • Enclosure: Open
  • Relay Style: Not applicable (Solid State)
  • Wire: 3 x AWG 3/0...500 kcmil
  • Amperage Maximum: 600A
  • Amperage Minimum: Not applicable
  • Nema Rating: Not specified
  • Switch Style: Circuit Breaker
  • Wire Size: 3 x AWG 3/0...500 kcmil
  • Certification: UL, CSA, NOM
  • Circuit Breaker Mounting Style: I-Line
  • Terminal Connection: I-Line Style Plug-In
  • Frequency Rating: 50/60 Hz
  • Phase Connection: 3-Phase
  • Standards: UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
  • Compatible Frames: I-Line
  • Installation Type: Plug-In
  • Item QTY: 1
  • Nema Starter Size: Not applicable
  • Breaker Frame: PLA
  • Current Rating: 600A
  • Reverse Standoff Voltage: Not applicable
  • Watts: Not specified
  • Peak Pulse Current: Not applicable
  • Breakdown Voltage (MIN VBR@IT ) (V): Not applicable
  • Breakdown Voltage (VBR@IT) (V): Not applicable
  • Polarity: Not applicable
  • Operating Temperature Maximum Celsius: 70 °C
  • Max Clamp Voltage: Not applicable
  • On-State Current: Not applicable


Product Identification
  • UPC: 762179036616
