The Square D PJA36060U44AE1 is a Powerpact molded case circuit breaker from Schneider Electric designed for primary overcurrent and ground fault protection in industrial power distribution systems. It is rated for 600V AC, 600A continuous current, and provides a 65kA interrupting capacity at 480V AC with solid-state LSIG (Long-Time, Short-Time, Instantaneous and Ground Fault) protection. This three-phase, three-pole unit features an I-Line style plug-in connection with AL800M23K terminal lugs, measures 8.05 inches deep by 8.27 inches wide by 12.86 inches high, and weighs 32 lb. It is certified to CE, UL, CSA, NEMA, NOM, IEC, and RoHS standards, and operates within a temperature range of -25 to 70 °C (-13 to 158 °F). The P-frame breaker is suited for switchboards, panelboards, and motor control centers requiring adjustable solid-state trip functionality.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Powerpact P Frame, Solid State Trip
  • Voltage Rating: 600V AC
  • Current Rating: 600A
  • Dimensions: Depth 8.05 in (204.47 mm), Width 8.27 in (210.06 mm), Height 12.86 in (326.64 mm)
  • Standards: CE, UL, CSA, NEMA, NOM, IEC, RoHS
  • Applications: Industrial switchboards, panelboards, motor control centers
  • Poles: 3
  • Phase: 3
  • Connection: I-Line Style Plug-In
  • Terminal Connection: AL800M23K
  • Functions: LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault
  • Frame Size: P Frame
  • Protection: Solid State
  • AIC Rating: 65kA@480V
  • Temp Rating: -25-70 °C (13-158 °F)
  • Weight: 32 lb
  • Country of Origin: United States


Product Identification
  • UPC: 785901069225
