Square D PJA36060U43AE1 - Powerpact 600A 3-Pole Breaker
Square D PJA36060U43AE1 - Powerpact 600A 3-Pole Breaker

Square D PJA36060U43AE1 - Powerpact 600A 3-Pole Breaker

Square D
Price
Save $-13,598.59
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Square D PJA36060U43AE1 is a Powerpact molded case circuit breaker designed for primary overcurrent protection in industrial power distribution systems. This three-phase, 600V unit is rated for 600A continuous current with a 65kA interrupting capacity at 480V, utilizing solid-state LSI (Long-Time, Short-Time and Instantaneous) trip functions for precise protection coordination. The breaker features an I-Line style plug-in connection with AL800M23K terminals, housed in a P Frame measuring 8.05 inches deep, 8.27 inches wide, and 12.86 inches tall, weighing 32 lb. It is certified to CE, UL, CSA, NEMA, NOM, IEC, and RoHS standards, ensuring compliance with global industrial safety requirements. Typical applications include main or feeder protection in switchboards, panelboards, and motor control centers within manufacturing plants, commercial facilities, and utility systems.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Powerpact P Frame, Solid State Protection
  • Voltage Rating: 600V AC
  • Current Rating: 600A
  • Dimensions: Depth 8.05 in (204.47 mm) Width 8.27 in (210.06 mm) Height 12.86 in (326.64 mm)
  • Standards: CE, UL, CSA, NEMA, NOM, IEC, RoHS
  • Applications: Industrial power distribution, switchboards, panelboards, motor control centers
  • Switch Type: I-Line Style Plug-In
  • Configuration: 3-Pole, 3-Phase
  • Coil Voltage Maximum: Not applicable (solid state trip)
  • Temp Rating: 13-158 °F (-25-70 °C)
  • Shipping Dimensions: Not specified
  • Phase: 3
  • Voltage: 600V
  • Amperage: 600A
  • AIC rating: 65kA@480V
  • Connection: I-Line Style Plug-In
  • Poles: 3
  • Protection: Solid State
  • Functions: LSI - Long-Time, Short-Time and Instantaneous
  • Frame Size: P Frame
  • Trip Type: Solid State
  • Panel Type: Not specified
  • Breaker Type: Powerpact
  • Control Voltage Minimum: Not applicable
  • Control Voltage Maximum: Not applicable
  • MCM Size: Not specified
  • Metal Type: Not specified
  • Panel Style: Not specified
  • Bus Type: Not specified
  • Fuse Class: Not applicable
  • Insulation Temperature: Not specified
  • Inductance: Not specified
  • Impedance: Not specified
  • Barrels: Not specified
  • Class Rating: Not specified
  • Diameter: Not specified
  • Velocity: Not specified
  • Clip Center: Not specified
  • Clas: Not specified
  • Mounting: I-Line Plug-In
  • Hz: Not specified
  • Coil Material: Not applicable
  • Horse Power: Not specified
  • Aux Contacts: Not specified
  • CPT: Not specified
  • Full Load Amps: Not specified
  • Dist Voltage: Not specified
  • Bucket Size: Not specified
  • Bucket Style: Not specified
  • Bucket Type: Not specified
  • Full Load Amp Maximum: Not specified
  • Full Load Amp Minimum: Not specified
  • Enclosure: Not specified
  • Relay Style: Not applicable
  • Coil Voltage Minimum: Not applicable
  • Wire: Not specified
  • Amperage Maximum: 600A
  • Amperage Minimum: Not specified
  • Nema Rating: Not specified
  • Switch Style: I-Line Plug-In
  • Wire Size: Not specified
  • Certification: CE, UL, CSA, NEMA, NOM, IEC, RoHS
  • Circuit Breaker Mounting Style: I-Line Plug-In
  • Terminal Connection: AL800M23K
  • Frequency Rating: Not specified
  • Phase Connection: 3-Phase
  • Standards: CE, UL, CSA, NEMA, NOM, IEC, RoHS
  • Compatible Frames: P Frame
  • Installation Type: Plug-In
  • Item QTY: 1
  • Nema Starter Size: Not applicable
  • Breaker Frame: P Frame
  • Current Rating: 600A
  • Reverse Standoff Voltage: Not applicable
  • Watts: Not specified
  • Peak Pulse Current: Not applicable
  • Breakdown Voltage (MIN VBR@IT ) (V): Not applicable
  • Breakdown Voltage (VBR@IT) (V): Not applicable
  • Polarity: Not applicable
  • Operating Temperature Maximum Celsius: 70 °C
  • Max Clamp Voltage: Not applicable
  • On-State Current: Not applicable


Product Identification
  • UPC: 762179029441
