Schneider Electric PGA36080CU31A - Molded Case 800A 600V 3-Pole
Schneider Electric PGA36080CU31A - Molded Case 800A 600V 3-Pole

Schneider Electric PGA36080CU31A - Molded Case 800A 600V 3-Pole

Square D
Price
Save $13,576.74
/
Condition
  • Low stock - 1 item left
  • Backordered, shipping soon
Call for Price
Schneider Electric Powerpact PGA36080CU31A is a 3-pole molded case circuit breaker designed for primary overcurrent protection in industrial power distribution systems. It is rated for 800A continuous current at 600VAC, with a 35kA interrupting capacity at 480VAC, and features solid-state trip technology providing LI (Long-Time and Instantaneous) protection functions. The unit measures 12.86 in (326.64 mm) in height, 8.27 in (210.06 mm) in width, and 8.05 in (204.47 mm) in depth, weighing 32 lb, and utilizes an I-Line style plug-in connection for panelboard mounting. It is certified to UL, CSA, NEMA, NOM-003-SCFI-2000, and IEC 60947-2 standards, and accepts 3 x AWG 3/0 to 500 kcmil aluminum or copper conductors. This breaker is typically applied in commercial and industrial switchboards, motor control centers, and distribution panels requiring high-ampacity, solid-state protection.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Solid State Trip, LI (Long-Time and Instantaneous) Functions
  • Voltage Rating: 600VAC
  • Current Rating: 800A
  • Dimensions: 12.86 in (326.64 mm) x 8.27 in (210.06 mm) x 8.05 in (204.47 mm) (Height x Width x Depth)
  • Standards: UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
  • Applications: Industrial power distribution, switchboards, motor control centers
  • Switch Type: Molded Case
  • Configuration: 3-Pole
  • Coil Voltage Maximum: Not applicable (solid state trip)
  • Temp Rating: Not specified
  • Shipping Dimensions: Not specified
  • Phase: 3
  • Voltage: 600V
  • Amperage: 800A
  • AIC rating: 35kA@480V
  • Connection: I-Line Style Plug-In
  • Poles: 3
  • Protection: Solid State (LI)
  • Functions: Long-Time and Instantaneous
  • Frame Size: Powerpact
  • Trip Type: Solid State
  • Panel Type: I-Line
  • Breaker Type: PGA
  • Control Voltage Minimum: Not applicable
  • Control Voltage Maximum: Not applicable
  • MCM Size: 3/0 to 500 kcmil
  • Metal Type: Not specified
  • Panel Style: I-Line
  • Bus Type: Not specified
  • Fuse Class: Not applicable
  • Insulation Temperature: Not specified
  • Inductance: Not specified
  • Impedance: Not specified
  • Barrels: Not specified
  • Class Rating: Not specified
  • Diameter: Not specified
  • Velocity: Not specified
  • Clip Center: Not specified
  • Clas: Not specified
  • Mounting: Plug-In
  • Hz: 50/60 Hz (typical)
  • Coil Material: Not applicable
  • Horse Power: Not specified
  • Aux Contacts: Not specified
  • CPT: Not specified
  • Full Load Amps: 800A
  • Dist Voltage: Not specified
  • Bucket Size: Not specified
  • Bucket Style: Not specified
  • Bucket Type: Not specified
  • Full Load Amp Maximum: 800A
  • Full Load Amp Minimum: Not specified
  • Enclosure: Not specified
  • Relay Style: Not applicable
  • Coil Voltage Minimum: Not applicable
  • Wire: 3 x AWG 3/0...500 kcmil aluminium/copper
  • Amperage Maximum: 800A
  • Amperage Minimum: Not specified
  • Nema Rating: Not specified
  • Switch Style: Molded Case
  • Wire Size: 3 x AWG 3/0...500 kcmil aluminium/copper
  • Certification: UL, CSA, NOM
  • Circuit Breaker Mounting Style: Plug-In
  • Terminal Connection: I-Line
  • Frequency Rating: 50/60 Hz (typical)
  • Phase Connection: 3-Phase
  • Standards: UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
  • Compatible Frames: Powerpact
  • Installation Type: Panelboard
  • Item QTY: 1
  • Nema Starter Size: Not applicable
  • Breaker Frame: PGA
  • Current Rating: 800A
  • Reverse Standoff Voltage: Not applicable
  • Watts: Not specified
  • Peak Pulse Current: Not applicable
  • Breakdown Voltage (MIN VBR@IT ) (V): Not applicable
  • Breakdown Voltage (VBR@IT) (V): Not applicable
  • Polarity: Not applicable
  • Operating Temperature Maximum Celsius: Not specified
  • Max Clamp Voltage: Not applicable
  • On-State Current: Not applicable


Product Identification
  • UPC: 785901574309
  • GTIN: 785901574309
