Eaton PDG3XTFA30500 - Thermal Magnetic Trip Unit 500A 600VAC
Eaton PDG3XTFA30500 - Thermal Magnetic Trip Unit 500A 600VAC

Eaton PDG3XTFA30500 - Thermal Magnetic Trip Unit 500A 600VAC

Eaton
Price
Save $-241.45
/
Condition
  • Low stock - 10 items left
  • Backordered, shipping soon
Call for Price
Eaton PDG3XTFA30500 is a 3-pole thermal-magnetic circuit breaker from the Power Defense Series, designed to provide LI (Long-Time and Instantaneous) protection for electrical systems. It is rated for 500A maximum amperage at 600VAC, with a current rating of 500A and a temperature range of -13 to 158 °F (-25 to 70 °C). The unit measures 8.31 in x 4.18 in x 5.18 in (Length/Depth x Height x Width), weighs 2.2 lb, and features standard line and load side lug terminal connections. It complies with RoHS standards and holds IEC, CSA, UL, and CCC certifications. This trip unit is compatible with PDG frames and is suited for industrial applications requiring reliable overcurrent protection.

Key Features & Specifications
  • Type: Thermal Magnetic Trip Unit
  • Voltage Rating: 600VAC
  • Current Rating: 500A
  • Dimensions: 8.31 in x 4.18 in x 5.18 in (Length/Depth x Height x Width)
  • Weight: 2.2 lb
  • Poles: 3
  • Protection: Thermal Magnetic
  • Functions: LI - Long-Time and Instantaneous
  • Terminal Connection: Standard Line and Load Side Lug
  • Temp Rating: -13 to 158 °F (-25 to 70 °C)
  • Standards: RoHS
  • Certification: IEC, CSA, UL, CCC
  • Compatible Frames: PDG
  • Amperage Maximum: 500
  • Family: Power Defense Series
  • Type: PDG


Product Identification
  • UPC: 786679589366
  • GTIN: 786679589366
