Eaton PDG13M0040TFFJ - 3-Pole Molded Case Breaker 40A 600V
Eaton PDG13M0040TFFJ - 3-Pole Molded Case Breaker 40A 600V

Eaton PDG13M0040TFFJ - 3-Pole Molded Case Breaker 40A 600V

Eaton
Price
Save $-317.38
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Eaton PDG13M0040TFFJ is a 3-pole molded case circuit breaker from the Power Defense Series, designed for thermal-magnetic overcurrent protection in industrial power distribution systems. It is rated for 600V AC and 40A, with an interrupting capacity of 65kA at 480V, and operates in a 3-phase configuration. The unit measures 6.7 in x 4.2 in x 3.8 in (Length/Depth x Height x Width), weighs 2.8 lb, and features a bolt-on connection with standard line and load side lugs. This breaker complies with CCC, CSA, IEC 60947-2, RoHS, and UL 489 standards, and is suitable for use in ambient temperatures ranging from -13°F to 158°F (-25°C to 70°C). Typical applications include industrial panelboards, switchboards, and motor control centers requiring reliable short-circuit and overload protection.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Power Defense Series, Thermal Magnetic Protection
  • Voltage Rating: 600V AC
  • Current Rating: 40A
  • Dimensions: 6.7 in x 4.2 in x 3.8 in (Length/Depth x Height x Width)
  • Standards: CCC, CSA, IEC 60947-2, RoHS, UL 489
  • Applications: Industrial panelboards, switchboards, motor control centers
  • Poles: 3
  • Connection: Bolt-On
  • Protection: Thermal Magnetic
  • AIC rating: 65kA@480V
  • Phase: 3
  • Temp Rating: -13°F to 158°F (-25°C to 70°C)
  • Terminal Connection: Standard Line and Load Side Lug
  • Weight: 2.8 lb
  • Country of Origin: Dominican Republic


Product Identification
  • UPC: 786679234471
  • GTIN: 00786679234471
