Eaton PDG12C0030TFFJ - 2-Pole 30A 600V Molded Case Breaker
Eaton PDG12C0030TFFJ - 2-Pole 30A 600V Molded Case Breaker

Eaton PDG12C0030TFFJ - 2-Pole 30A 600V Molded Case Breaker

Eaton
Price
Save $-357.31
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Eaton PDG12C0030TFFJ is a 2-pole molded case circuit breaker from the Power Defense Series, designed for overcurrent protection in industrial and commercial power distribution systems. It features a 30A current rating and a 600V voltage rating, with a thermal magnetic protection mechanism providing long-time and instantaneous trip functions (LI) for reliable fault interruption. This feed-thru breaker weighs 7.5 lb and includes standard line and load side lugs for terminal connection, operating within a temperature range of -13 to 158 °F (-25 to 70 °C). It is certified to UL 489, CSA, IEC 60947-2, CCC, and RoHS standards, with an AIC rating of 18kA at 480V. Typical applications include branch circuit protection in panelboards, switchboards, and motor control centers.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Power Defense Series, PDG type, thermal magnetic protection
  • Voltage Rating: 600V
  • Current Rating: 30A
  • Poles: 2
  • Phase: 1
  • AIC Rating: 18kA@480V
  • Connection: Feed-Thru
  • Terminal Connection: Standard Line and Load Side Lug
  • Functions: LI - Long-Time and Instantaneous
  • Temp Rating: -13–158 °F (-25–70 °C)
  • Weight: 7.5 lb
  • Certification: CCC, CSA, IEC 60947-2, RoHS, UL 489
  • Installation Type: Fixed
  • Circuit Breaker Mounting Style: Panel Mount
  • Frequency Rating: 50/60 Hz
  • Standards: UL 489, CSA, IEC 60947-2
