Bussmannn NOS-250 - Class H Fuse 250A 600V (10kA AIC Rating)

Bussmannn NOS-250 is a Class H low-voltage fuse designed for high-current circuit protection in industrial applications. Rated for 600V AC/DC systems with a 250A current capacity, it features a rugged single-barrel construction with 10kA interrupting capacity at rated voltage. The fuse measures 11.63" in length and 2.59" in diameter, constructed to meet stringent industry standards for electrical safety. Compliant with UL/CSA requirements, it provides reliable protection for motor circuits, transformers, and heavy industrial equipment where high fault currents may occur.

Key Features & Specifications

• Type: NOS Series Class H single-barrel fuse
• Voltage Rating: 600V AC/DC
• Current Rating: 250A
• Dimensions: 11.63"L x 2.59"W x 2.59"H
• Weight: 3 lb
• Diameter: 2.59 inches
• AIC Rating: 10kA @ 600V
• Standards: UL/CSA compliant
• Applications: Industrial motor protection, transformer circuits, heavy equipment
• Class Rating: H
• Barrels: 1

Product Identification

• UPC: 051712312509
• GTIN: 00051712312509
