Eaton Bussmann NOS-175 - RK5 Time-Delay Fuse 175A 600V

Bussmann
Price
Save $165.79
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Eaton Bussmann NOS-175 is a low-voltage, time-delay fuse designed for branch circuit and feeder protection in industrial electrical systems. It features a 175A current rating and a 600V AC voltage rating, with a 10kA interrupting capacity at that voltage. The fuse is constructed as a single-barrel, RK5 class device with a 1.84-inch diameter and a 9.63-inch length, weighing 1.2 lb, and it complies with key industry standards including UL and CSA. This fuse is typically applied to protect motor circuits, transformers, and other equipment where a high degree of inrush current tolerance is required.

Key Features & Specifications
  • Type: Low-voltage, time-delay, current-limiting fuse, RK5 class, single barrel
  • Voltage Rating: 600V AC
  • Current Rating: 175A
  • Dimensions: 9.63 in L x 1.84 in H x 1.84 in W (Diameter: 1.84 in)
  • Weight: 1.2 lb
  • Standards: UL Listed (File E4273), CSA Certified (Class 1421-01, File 53787), CE, Guide JDDZ, STD 248-6
  • AIC Rating: 10kA @ 600V
  • Country of Origin: Mexico


Product Identification
  • UPC: 051712311755
  • GTIN: 00051712311755
