Bussmann NOS-150 - Class H Renewable Fuse 150A 600V (10kA AIC Rating)

Bussmann NOS-150 is a Class H low-voltage fuse designed for circuit protection in industrial power distribution systems. It features a 150A current rating and 600V AC voltage rating with an interrupting capacity of 10kA at 600V. The single-barrel construction measures 9-5/8 inches in length with a 1.84-inch diameter and weighs 1 lb, built for durable performance in demanding environments. This fuse complies with UL Standard 248-6 and carries CE, UL Listed, and CSA certifications for reliable operation. Typical applications include motor branch circuits, feeder circuits, and industrial control panels where robust overcurrent protection is required.

Key Features & Specifications

• Type: Class H renewable fuse, single barrel construction
• Voltage Rating: 600V AC
• Current Rating: 150A
• Dimensions: 9-5/8 inches length, 1.84 inches diameter
• Standards: UL 248-6, CE, UL Listed, CSA Certified
• Applications: Industrial power distribution, motor circuits, feeder protection
• AIC rating: 10kA@600V
• Class Rating: H
• Barrels: 1
• Weight: 1 lb
• Certification: CE, UL Listed, Guide JDDZ, File E4273, STD 248-6, CSA Certified Class 1421-01, File 53787

Product Identification

• UPC: 051712311502
• GTIN: 00051712311502
