Bussmann NOS-15 - Low Voltage Fuse 15A (50kA Interrupt Rating @600V)

Bussmann NOS-15 is a low-voltage fuse designed for circuit protection in industrial electrical systems, featuring a 15A current rating and 600V voltage capacity. Its Class K5 construction with a single-barrel design and 0.81-inch diameter provides reliable interruption of up to 50kA short-circuit currents at rated voltage. The 5-inch cylindrical fuse body meets UL, CSA, and CE certifications (File E4273/53787) with compliance to STD 248-9 standards. Typical applications include motor control centers, switchgear, and power distribution panels requiring robust overcurrent protection.

Key Features & Specifications

• Type: NOS-series cylindrical fuse with Class K5 current-limiting design
• Voltage Rating: 600V AC/DC
• Current Rating: 15A
• Dimensions: 5" length x 0.81" diameter
• Standards: UL Listed (File E4273), CSA Certified (Class 1421-01), CE, Guide JDDZ
• Applications: Industrial switchgear, motor protection, power distribution
• AIC rating: 50kA@600V
• Class Rating: K5
• Barrels: 1
• Weight: 1.153 lb
• Country of Origin: Mexico

Product Identification

• UPC: 051712310154
• GTIN: 00051712310154
