Bussmann NON-6 - Low Voltage Fuse 6A 250V (K5 Class 50kA AIC)

Bussmann NON-6 is a low voltage current-limiting fuse designed for circuit protection in industrial applications. It features a 6A current rating and 250V voltage rating with a 50kA interrupting capacity, providing reliable overcurrent protection. The single-barrel construction measures 2 inches in length with a 0.56-inch diameter and carries a K5 class rating for time-delay characteristics. This fuse meets UL, CSA, and CE standards including UL File E4274 and CSA File 53787. Typical applications include motor branch circuits, transformers, and industrial control panels where coordinated protection is required.

Key Features & Specifications

• Type: NON Series current-limiting time-delay fuse
• Voltage Rating: 250V AC
• Current Rating: 6A
• Dimensions: 2 inches length, 0.56 inches diameter
• Standards: UL Listed, CSA Certified, CE marked
• Applications: Motor circuits, transformers, control panels
• AIC rating: 50kA@250V
• Class Rating: K5
• Barrels: 1
• Weight: 1.35 lb
• Family: NON Series
• Country of Origin: Mexico

Product Identification

• UPC: 051712300063
• GTIN: 00051712300063
