Eaton Bussmann NON-5 - Class K5 Fuse 5A 250V (50kA AIC Rating)

Eaton Bussmann NON-5 is a low-voltage current-limiting fuse designed for circuit protection in industrial applications. It features a 5A current rating and 250V voltage rating with a 50kA interrupting capacity at rated voltage. The fuse construction includes a single-barrel design measuring 2 inches in length with 0.56-inch diameter and 1.35 lb weight, built to Class K5 standards. This component meets multiple certifications including UL Listed, CSA Certified Class 1421-01, and CE compliance standards. Typical applications include industrial control circuits, motor branch circuits, and feeder protection systems where reliable overcurrent protection is required.

Key Features & Specifications

• Type: NON Series low-voltage current-limiting fuse, single-barrel construction
• Voltage Rating: 250V AC
• Current Rating: 5A
• Dimensions: 2 inches length, 0.56 inches diameter
• Standards: UL Listed (File E4274), CSA Certified Class 1421-01 (File 53787), CE, Guide JDDZ, STD 248-9
• Applications: Industrial control circuits, motor branch circuits, feeder protection
• AIC rating: 50kA@250V
• Class Rating: K5
• Barrels: 1
• Weight: 1.35 lb
• Family: NON Series
• Country of Origin: Mexico

Product Identification

• UPC: 051712300056
• GTIN: 00051712300056
