Bussmannn NON-40 - Low-Voltage Fuse 40A (50kA AIC @250V)

Bussmannn NON-40 is a low-voltage fuse designed for circuit protection in industrial and commercial applications. Rated for 250V AC/DC systems with a 40A current capacity, it features a compact cylindrical design (0.81" diameter x 3" length) and weighs 1.01 lb. The fuse meets UL, CSA, and CE standards with a 50kA interrupting rating at 250V, ensuring reliable short-circuit protection. Its K5-class construction provides time-delay characteristics for motor and transformer applications.

Key Features & Specifications

• Type: NON-series time-delay fuse with ceramic body
• Voltage Rating: 250V AC/DC
• Current Rating: 40A
• Dimensions: 0.81" diameter x 3" length
• Standards: UL Listed (File E4274), CSA Certified (Class 1421-01), CE
• Applications: Motor circuits, transformers, industrial controls
• Class Rating: K5
• AIC Rating: 50kA@250V
• Barrels: 1
• Weight: 1.01 lb

Product Identification

• UPC: 051712101615
• GTIN: 00051712101615
