Bussmann NON-35 - Class K5 Fuse 35A 250V (50kA AIC Rating)

Bussmann NON-35 is a low-voltage current-limiting fuse designed for circuit protection in industrial electrical systems. It features a 35A current rating and 250V voltage rating with a 50kA interrupting capacity, providing reliable overcurrent protection. The fuse measures 3 inches in length with a 0.81-inch diameter and features a single-barrel construction weighing 1.1 lb. It complies with UL, CSA, and CE standards including UL File E4274 and CSA File 53787. Typical applications include industrial control circuits, motor branch circuits, and feeder protection where Class K5 performance is required.

Key Features & Specifications

• Type: NON series current-limiting fuse with single-barrel construction
• Voltage Rating: 250V AC
• Current Rating: 35A
• Dimensions: 3" length x 0.81" diameter
• Standards: UL Listed (File E4274), CSA Certified (Class 1421-01, File 53787), CE, Guide JDDZ, STD 248-9
• Applications: Industrial control circuits, motor protection, feeder circuits
• AIC rating: 50kA@250V
• Class Rating: K5
• Barrels: 1
• Weight: 1.1 lb
• Country of Origin: Mexico
• Item Subcategory: Low Voltage Fuse
• Family: NON Series

Product Identification

• UPC: 051712101608
• GTIN: 00051712101608
