Bussmann NON-250 - Class H Fuse 250A (10kA AIC @250V)

Bussmann NON-250 is a Class H low-voltage fuse designed for overcurrent protection in industrial electrical systems. It features a 250V AC voltage rating and 250A current rating with a 10kA interrupting capacity at 250V for reliable circuit protection. The fuse measures 8.63 inches in length with a 2.06-inch diameter cylindrical body and weighs 1 lb, constructed as a single-barrel design for straightforward installation. This fuse meets industry standards for Class H fuses and is typically applied in motor circuits, feeder circuits, and industrial power distribution systems where robust overcurrent protection is required.

Key Features & Specifications

• Type: Class H low-voltage fuse, single-barrel construction
• Voltage Rating: 250V AC
• Current Rating: 250A
• Dimensions: 8.63" L × 2.06" H × 2.06" W
• Standards: Class H fuse standards
• Applications: Industrial motor circuits, feeder circuits, power distribution
• AIC rating: 10kA@250V
• Diameter: 2.06 inches
• Class Rating: H
• Barrels: 1
• Weight: 1 lb

Product Identification

• UPC: 051712302500
• GTIN: 00051712302500
