Bussmann NON-2-1/2 - Low Voltage Fuse 2A 250V (K5 Class 50kA AIC)

The Bussmann NON-2-1/2 is a low-voltage current-limiting fuse designed to provide reliable overcurrent protection in industrial electrical systems. It features a 2A current rating and a 250V AC voltage rating, with a high interrupting capacity of 50kA. The fuse is constructed as a single-barrel device with a 0.56-inch diameter and a 2-inch length, built to K5 class standards for time-delay characteristics. It complies with major safety standards including UL and CSA certification. This fuse is typically applied in the protection of motor circuits and transformers where a time-delay characteristic is required to handle temporary inrush currents.

Key Features & Specifications

• Type: NON Series, Low Voltage, Current-Limiting, Time-Delay (K5 Class), Single Barrel
• Voltage Rating: 250V AC
• Current Rating: 2A
• Dimensions: 2 in Length, 0.56 in Diameter
• Standards: UL Listed (File E4274, STD 248-9), CSA Certified (Class 1421-01, File 53787), CE
• Applications: Motor Circuit Protection, Transformer Protection
• AIC rating: 50kA @ 250V AC
• Class Rating: K5
• Barrels: 1
• Certification: CE, UL Listed, Guide JDDZ, File E4274, STD 248-9, CSA Certified Class 1421-01, File 53787
• Weight: 1.35 lb

Product Identification

• UPC: 051712300186
• GTIN: 00051712300186
