Bussmann NON-12 - Time-Delay Fuse 12A 250V (K5 Class 50kA AIC)

Bussmann NON-12 is a low-voltage fuse designed for circuit protection in industrial applications. It features a 12A current rating and 250V voltage rating with a 50kA interrupting capacity at rated voltage. The fuse measures 2 inches in length with a 0.56-inch diameter and utilizes a single-barrel construction with K5 class rating for time-delay characteristics. It complies with UL, CSA, and CE standards including UL File E4274 and CSA File 53787. This fuse is typically employed in motor branch circuits, transformers, and industrial control panels where coordinated protection is required.

Key Features & Specifications

• Type: NON Series time-delay fuse, single barrel construction
• Voltage Rating: 250V AC
• Current Rating: 12A
• Dimensions: 2 inches length, 0.56 inches diameter
• Standards: UL Listed, CSA Certified, CE compliant
• Applications: Motor circuits, transformers, industrial control panels
• AIC rating: 50kA@250V
• Class Rating: K5
• Barrels: 1
• Certification: UL Listed (File E4274), CSA Certified (Class 1421-01, File 53787), CE, Guide JDDZ, STD 248-9
• Weight: 1.35 lb
• Family: NON Series
• Country of Origin: Mexico

Product Identification

• UPC: 051712300087
• GTIN: 00051712300087
