Bussmann NON-10 - Class K5 Fuse 10A (50kA AIC @ 250V)

Bussmann NON-10 is a low-voltage current-limiting fuse designed for overcurrent protection in industrial electrical systems. It features a 10A current rating and 250V voltage rating with a high interrupting capacity of 50kA at 250V AC. The fuse construction includes a single-barrel design measuring 2 inches in length with a 0.56-inch diameter and weighs 1.25 lb. It complies with multiple industry standards including UL, CSA, and CE certifications with Class K5 rating. Typical applications include motor branch circuit protection, industrial control panels, and electrical distribution equipment where reliable current limitation is required.

Key Features & Specifications

• Type: NON Series current-limiting fuse, single barrel construction
• Voltage Rating: 250V AC
• Current Rating: 10A
• Dimensions: 2 in length x 0.56 in diameter
• Standards: UL Listed (File E4274), CSA Certified (Class 1421-01, File 53787), CE, Guide JDDZ, STD 248-9
• Applications: Motor branch circuits, industrial control panels, electrical distribution systems
• AIC rating: 50kA@250V
• Class Rating: K5
• Barrels: 1
• Weight: 1.25 lb
• Family: NON Series
• Country of Origin: Mexico

Product Identification

• UPC: 051712101554
• GTIN: 00051712101554
