Siemens MD-T - Molded Case Circuit Breaker 150A 2-Pole (10kA AIC)
Siemens MD-T - Molded Case Circuit Breaker 150A 2-Pole (10kA AIC)

Siemens MD-T - Molded Case Circuit Breaker 150A 2-Pole (10kA AIC)

Murray
Price
Save $757.91
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
The Siemens MD-T is a molded case circuit breaker designed for reliable overcurrent protection in industrial and commercial electrical systems. It provides a 150A current rating and 240V voltage rating for single-phase applications, featuring a compact plug-in design with dimensions of 7.48 x 3.937 x 2.362 inches and a weight of 1.301 lb. This UL-certified breaker utilizes a thermal-magnetic trip mechanism for both long-time and instantaneous protection, achieving an interrupting capacity of 10kA at 240V. Its construction supports copper or aluminum conductors from 4 AWG to 300 kcmil, making it suitable for panelboards, switchboards, and motor control centers requiring robust circuit protection.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Protection, Plug-In Connection
  • Voltage Rating: 240V AC
  • Current Rating: 150A
  • Dimensions: 7.48 x 3.937 x 2.362 inches (190mm x 100mm x 60mm)
  • Standards: UL Certified
  • Applications: Panelboards, Switchboards, Motor Control Centers, Industrial Distribution
  • Phase: 1
  • Poles: 2
  • AIC Rating: 10kA @ 240V
  • Connection: Plug-In
  • Protection: Thermal Magnetic
  • Functions: Long Time and Instantaneous Trip
  • Wire Size: 4 AWG to 300 kcmil, Copper/Aluminum
  • Family: MD Series
  • Country of Origin: Mexico
  • Weight: 1.301 lb (0.59 kg)


Product Identification
  • UPC: 040892006469
  • GTIN: 00040892006469
