Bussmannn MDA-7-R - MDA Series Fuse 7A@250V (200A AIC)

Bussmannn MDA-7-R is a low-voltage ferrule-type fuse designed for circuit protection in industrial electrical systems. This 7A/250V fuse features a compact 1-1/4" cylindrical design with 0.25" diameter and 1 lb weight, constructed with a single-barrel ferrule connection for secure installation. It meets CE, CSA Class 1422-01, and UL 248-14 (JDYX) standards with a 200A interrupting capacity at 250V. The MDA series fuse is commonly used in control panels, motor circuits, and power distribution equipment requiring reliable overcurrent protection.

Key Features & Specifications

• Type: MDA series ferrule fuse, single-element construction
• Voltage Rating: 250V AC/DC
• Current Rating: 7A
• Dimensions: 1-1/4" length x 0.25" diameter
• Weight: 1 lb
• Connection: Ferrule terminal
• Barrels: 1
• AIC Rating: 200A@250V
• Standards: CE, CSA Class 1422-01, UL 248-14 (JDYX)
• Applications: Industrial control circuits, motor protection, power distribution

Product Identification

• UPC: 05171264538
• GTIN: 00051712645386
