Schneider Electric LX1FF092 - Magnetic Coil 110VAC 2000A
Schneider Electric LX1FF092 - Magnetic Coil 110VAC 2000A

Schneider Electric LX1FF092 - Magnetic Coil 110VAC 2000A

Schneider Electric
Price
Save $8.43
/
Condition
  • Low stock - 1 item left
  • Backordered, shipping soon
Call for Price
Schneider Electric LX1FF092 is a magnetic coil designed for motor control applications, serving as a replacement coil for TeSys F contactors. It operates at 110 VAC at 60 Hz and provides LI (Long-Time and Instantaneous) protection functions, with a solid-state protection system and a bolt-on connection. This 3-pole, 3-phase unit has a current rating of 2000A and an AIC rating of 65kA at 480V, weighing 1.038 lb. The coil features an inductance of 0.59 H, an average resistance of 4.55 Ohm at 20 °C, and offers mechanical durability up to 10 million cycles with a maximum operating rate of 2400 cycles per hour at 131°F (55°C). It is suitable for use in industrial motor control systems requiring reliable and durable performance.

Key Features & Specifications
  • Type: Contactor coil
  • Functions: LI - Long-Time and Instantaneous
  • Voltage Rating: 110V
  • Poles: 3
  • Connection: Bolt-On
  • Protection: Solid State
  • AIC rating: 65kA@480V
  • Phase: 3
  • Current Rating: 2000A
  • Weight: 1.038 lb
  • Control circuit voltage: 110 V AC 60 Hz
  • Inductance: 0.59 H
  • Average resistance: 4.55 Ohm at 20 °C
  • Mechanical durability: 10 million cycles
  • Maximum operating rate: 2400 cycles/hour at 131°F (55°C)
  • Heat dissipation: 12–16 W at 60 Hz
  • Operating temperature range: -5 to 55 °C
