ABB LT9350SC - Safety Switch 600V 30A NEMA 3R
ABB LT9350SC - Safety Switch 600V 30A NEMA 3R

ABB LT9350SC - Safety Switch 600V 30A NEMA 3R

Steel City
Price
Save $-234.91
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
ABB LT9350SC is a heavy-duty industrial safety switch designed for reliable circuit protection and disconnection in commercial and industrial power distribution systems. It is rated for 600 volts AC and 30 amperes, providing robust performance for motor and equipment control. The switch features a NEMA 3R rainproof enclosure constructed from galvanized steel, measuring approximately 10 inches in height, 6 inches in width, and 5 inches in depth, with a weight of 5.19 pounds. It complies with UL 98 and NEMA standards, ensuring safe operation in demanding environments. Typical applications include service entrance, feeder, and branch circuit disconnection in factories, warehouses, and outdoor installations.

Key Features & Specifications
  • Type: Heavy-duty safety switch, non-fusible, with a visible blade design for positive ON/OFF indication
  • Voltage Rating: 600 V AC
  • Current Rating: 30 A
  • Dimensions: 10 x 6 x 5 inches (approximate)
  • Standards: UL 98, NEMA 3R
  • Applications: Service entrance, feeder, and branch circuit disconnection for motors, lighting, and equipment
  • Enclosure: NEMA 3R rainproof, galvanized steel
  • Switch Style: Non-fusible, heavy-duty
  • Phase: Single-phase
  • Voltage: 600 V AC
  • Amperage: 30 A
  • Connection: Wire terminals for copper/aluminum conductors
  • Poles: 2-pole
  • Protection: Overcurrent protection via external fuses (not included)
  • Functions: ON/OFF disconnection
  • Mounting: Surface mount
  • Hz: 50/60 Hz
  • Horse Power: Suitable for motor loads up to 10 HP at 600 V
  • Nema Rating: NEMA 3R
  • Terminal Connection: Screw-type lugs
  • Frequency Rating: 50/60 Hz
  • Phase Connection: Single-phase
  • Standards: UL 98, NEMA
  • Installation Type: Surface mount
  • Item QTY: 1
  • Current Rating: 30 A
  • Operating Temperature Maximum Celsius: 40°C


Product Identification
  • UPC: 78599108577
  • GTIN: 00785991085778
