Bussmannn LPJ-110SPI - Class J Fuse 110A (300kA@600V Interrupt Rating)

Bussmannn LPJ-110SPI is a Class J low-voltage fuse designed for circuit protection in industrial electrical systems. It features a 600V AC rating with a 110A current capacity and 300kA interrupting rating at 600V for reliable short-circuit protection. The fuse measures 5-3/4 inches in length with a 1.63-inch diameter, constructed as a single-barrel design with UL/CSA-certified special purpose protection. Compliant with CE/UL-Special Purpose Guide JFHR and CSA Class 1422-02 standards, this Low-Peak series fuse is commonly used in motor branch circuits, transformers, and feeder protection applications.

Key Features & Specifications

• Type: LPJ Class J time-delay fuse
• Voltage Rating: 600V AC
• Current Rating: 110A
• Dimensions: 5-3/4" length x 1.63" diameter
• Standards: CE/UL-Special Purpose Guide JFHR, CSA Class 1422-02
• Applications: Motor circuits, transformers, feeder protection
• Class Rating: J
• Barrels: 1
• AIC rating: 300kA@600V
• Weight: 1 lb
• Country of Origin: Mexico

Product Identification

• UPC: 051712627696
• GTIN: 00051712627696
